DRIVE FAST. BRAKE LAST.
R 340+
– maximum performance, consistent pedal feel, and highest reliability under extreme conditions..
RAVENOL Racing Brake Fluid
High-End-Performance
Setting new standards in motorsport: high-performance brake fluid designed for extreme thermal, chemical, and mechanical loads
OFFICIAL SUPPLIER
PERFORMANCE OVERVIEW
DOT-4-compliant:
High-End-Formulation:
Extremely heat resistant:
superior racing performance with full roadworthiness
based on borate ester and glycol ethers, perfected with state-of-the-art additives
max. boiling point 342°C
WERBP / wet boiling point min. 210°C
FEATURE HIGHLIGHTS
1. Superior Minimal Compressibility
Experience maximum control, even during extreme braking maneuvers.
-
Consistent, precise pedal feel – even under continuous high load
-
Shorter pedal travel – even at extreme temperatures
-
Stable braking performance – despite dynamic temperature fluctuations
2. Optimized Fluid Sound Speed
For a brake system that reacts instantly.
-
Ultra-fast initial response to pedal input
-
Minimal hydraulic delay
-
Immediate feedback for every driver input
-
Shorter stopping distances thanks to faster execution of brake commands
3. Thermal Peak Stability
No performance drop at the limit.
-
Consistent performance throughout the entire race duration
-
High resistance to fading at continuously elevated temperatures
-
Stable and transparent brake balance despite temperature dynamics
-
Longer effective service life under extreme conditions
4. Highest Boiling Point & Ideal Viscosity
The performance reserve that ensures safety in every racing scenario.
-
Extremely high protection against vapor lock
-
Superior maximum boiling point maintains brake functionality in extreme situations
-
Perfect lubrication of all brake system components
-
Optimal sealing performance throughout the system
5. Optimal Heat Capacity
Dissipate heat — perfect performance.
-
Balanced heat absorption without further performance degradation
-
Allows the brake system to maintain optimal thermal management
-
Consistent thermal expansion characteristics
TECHNICAL DATA
-
Specifications / Testing::
-
Exceeds the requirements of FMVSS 116 DOT 4
-
Tested and recommended according to ISO 4925-4 and SAE J1704
-
-
Dry boiling point: >340 °C (FMVSS 116)
-
Wet boiling point: 213 °C (FMVSS 116)
-
Viscosity (−40 °C): 1739 cSt (ASTM D445)
-
Viscosity (100 °C): 3,08 cSt (ASTM D445)
-
Water content: < 0,05 % (DIN 51777-1)
-
Note: All values correspond to our technical datasheet and the current state of knowledge. Subject to change..
SCAN TO DOWNLOAD
Maximum thermal stability
DEVELOPED AND TESTED IN MOTORSPORT
RAVENOL Racing Brake Fluid R 340+
FREQUENTLY ASKED QUESTIONS
What sets R 340+ apart from other high-end brake fluids?
Superior dry and wet boiling points, unmatched stability, and exceptional ease of use—while fully meeting DOT 4 requirements for perfect road legality.
How often should it be changed?
For pure motorsport use: refill with fresh fluid before every race.
For track days: depends on temperature peaks and moisture absorption.
For road use: follow the vehicle manufacturer’s DOT 4 service intervals.
Compatible with ABS/ESP?
Yes, its properties and viscosity range are suitable for modern systems (always follow the manufacturer’s specifications).
TYPICAL APPLICATIONS
-
Racetrack use (endurance, sprint, track days) – refill with fresh fluid before each event.
-
Performance braking systems with steel or carbon discs (verify compatibility according to DOT specifications).
IMPORTANT NOTES
-
Do not mix with other brake fluids.
-
Not suitable for systems requiring mineral-based brake fluid (LHM).
-
Not recommended for components made of magnesium or Mg-rich alloys.
-
Always observe manufacturer and vehicle specifications.
